CNC Hydraulic Die Forging Hammer

CNC Hydraulic Die Forging Hammers are widely applied in automobile forgings, motorcycle forgings, hardware forgings, hand tools blank forgings, stainless steel tableware, and aeronautic forgings etc, especially for the precision forging field. CNC hydraulic die forging hammer complied with low carbon production, low hammer running cost production and high efficiency production etc high requirements in modern forging industry.


Features:

1. Programmable hitting
2. Precise energy control
3. High forging accuracy
4. High blow frequencies
5. Simple and safe operating
6. Low forging vibration
7. Optimum die life and hammer rod life
8. Realize automatic production line

  • Parameters
  • Manufacturing
  • Video
  • Customer
  • Application Fields
  • Download

Parameters



MODEL C92K-12.5 C92K-16 C92K-20 C92K-25 C92K-31.5 C92K-40 C92K-50 C92K-63
Hit energy(KJ) 12.5 16 20 25 31.5 40 50 63
Weight of falling parts(kg) 860 1080 1350 1700 2150 2700 3400 4300
Max hit number(min-1) 129 122 123 113 100 98 98 98
Hit stroke(mm) 420-620 435-635 455-665 470-685 490-755 510-790 530-775 550-805
Working oil pressure(Mpa) 20 20 20 20 20 20 20 20
Main motor power(KW) 37 37 55 55 55 75 2*55 2*55
Machine weight(kg) 19000 27000 30000 39300 48000 58000 78500 95000
MODEL C92K-80 C92K-100 C92K-125 C92K-160 C92K-200 C92K-250 C92K-320 C92K-400
Hit energy(KJ) 80 100 125 160 200 250 320 400
Weight of falling parts(kg) 5400 6800 8500 10800 13700 17100 21000 27000
Max hit number(min-1) 92 81 70 70 60 50 45 40
Hit stroke(mm) 570-835 595-885 615-920 640-960 740-1060 770-1100 740-1150 860-1200
Working oil pressure(Mpa) 20 20 20 20 20 20 20 20
Main motor power(KW) 2*90 2*90 2*132 3*90 4*90 4*90 4*110 6*110
Machine weight(kg) 120000 148000 195000 235000 275000 330000 410000 465000
